DQ400 0DD DSG Mechatronic N218 Solenoid & Strainer Gasket Repair Kit
DQ400 0DD DSG Mechatronic N218 Solenoid & Strainer Gasket Repair Kit
SKU:AWT-DQ400-N218-KIT
COMING SOON!
DQ400 0DD DSG Mechatronic N218 Solenoid & Strainer Gasket Repair Kit
Complete repair kit for the DQ400 0DD 6-speed DSG mechatronic unit fitted to a range of Volkswagen Group plug-in hybrid vehicles.
A known issue with these mechatronic units is restriction of the small filter strainers incorporated into the hydraulic sealing gaskets. As contamination builds up within the strainers, hydraulic flow to the N218 solenoid can become restricted, causing transmission faults and problems with the vehicle's hybrid drivetrain.
This kit provides the components required to address this common failure, including a replacement N218 solenoid together with four replacement hydraulic sealing gaskets incorporating new filter strainers.
The Common DQ400 Strainer Problem
The original DQ400 mechatronic sealing gaskets contain small integrated filter strainers. Over time these strainers can become contaminated and restricted, reducing the hydraulic oil flow through the mechatronic unit.
When the strainer supplying the N218 solenoid becomes restricted, insufficient oil flow can prevent the solenoid from operating correctly. Replacing the gaskets renews the integrated strainers rather than leaving the original restricted filters in place.
Common Fault Codes
- P288400 - Engine Disconnect Clutch Stuck Open / Stuck Closed
- P172400 - Transmission related fault associated with the K0 clutch / hydraulic operation
Possible Symptoms
- Internal combustion engine will not start through the K0 clutch
- Vehicle may operate using electric drive only
- Transmission or hybrid system warning messages
- Emergency or reduced-function mode
- Stored DQ400 mechatronic or K0 clutch fault codes
What's Included
- 1 x N218 electromagnetic solenoid valve
- 4 x DQ400 mechatronic hydraulic sealing gaskets
- New filter strainers integrated into the replacement gaskets
Important Repair Information
Simply replacing the N218 solenoid without addressing restricted strainers may not rectify the underlying cause of the fault. This kit includes both the replacement solenoid and replacement sealing gaskets with new strainers so the affected hydraulic filtration components can be renewed at the same time.
Compatibility
Designed for Volkswagen Group plug-in hybrid vehicles fitted with the DQ400 / 0DD 6-speed DSG transmission.
- Audi A3 e-tron
- Audi Q3 e-tron
- Cupra Formentor e-Hybrid
- Skoda Octavia iV
- Skoda Superb iV
- Volkswagen Golf GTE
- Volkswagen Passat GTE
OEM Reference Numbers
This repair kit is suitable for a range of DQ400 / 0DD mechatronic variants. Common OEM reference numbers associated with compatible units include:
0DD927770A, 0DD927770B, 0DD927770C, 0DD927770D, 0DD927770E,
0DD325065E, 0DD325066C, 0DD325025E, 0DD325477B,
0DD325737B R02, 0DD927313B R02, 0DD927737B R01, 0DD927737B,
0DD325557A, 0DD325541C, 0DD325542C, 0DD325467B, 0DD325483B,
0DD325477B R02, 0DD927327E R01, 0DD927327G R01, 0DD927327C R01,
0DD325477F R01, 0DD325542B
Please Check Before Ordering
The OEM numbers above are provided as reference numbers for compatible DQ400 / 0DD applications. Please confirm your transmission and mechatronic version before ordering. If you're unsure, contact us with your vehicle registration and mechatronic part number and we'll be happy to check the application.
Professional Installation Required
Installation requires removal and disassembly of the DQ400 mechatronic unit. Correct diagnosis, cleanliness and appropriate transmission repair procedures are essential. This repair should be carried out by a technician experienced with DSG and hybrid transmission systems.
Frequently Asked Questions
What normally causes this DQ400 fault?
A known issue is restriction of the small filter strainers incorporated into the mechatronic hydraulic sealing gaskets. If a strainer becomes restricted, hydraulic oil flow to the associated solenoid can be reduced and prevent the system from operating correctly.
Do the new gaskets include new strainers?
Yes. The replacement sealing gaskets supplied in this kit incorporate new filter strainers, allowing the original strainers to be replaced as part of the repair.
Does the kit include the N218 solenoid?
Yes. The kit includes one replacement N218 electromagnetic solenoid valve together with the four replacement mechatronic sealing gaskets.
Can I just replace the N218 solenoid?
Replacing the solenoid alone may not address the underlying problem if hydraulic flow is being restricted by a contaminated strainer. For this reason the kit includes replacement gaskets with new strainers as well as the N218 solenoid.
Is this for the DQ200 gearbox?
No. This repair kit is specifically for applicable DQ400 / 0DD 6-speed DSG transmissions used in Volkswagen Group plug-in hybrid vehicles.
Will this repair every DQ400 mechatronic fault?
No. DQ400 mechatronic faults can have several different causes. The transmission should be correctly diagnosed before ordering parts to confirm that the fault relates to the components included in this kit.
| Confirmed Applications | ||||||
| Audi | Seat | Skoda | Volkswagen | BMW | Mini | Toyota |
|
A3 8V A3 8Y Q3 MK2 |
Formentor |
Octavia MK4 (NX) Superb MK3 (3V) |
Golf MK7 Golf MK8 Passat B8 |
|||
